CATEGORY |
SPECIFICATIONS |
|---|---|
| Body Material | ABS/FRP |
| Color | Customer preference |
| Overall Dimension | 508 cm x 148.5 cm x 191 cm |
| Capacity | 13 seating passengers + 1 driver |
| Load Capacity | 1,050 kg |
| Normal Operating Speed | 35-50 kph |
| Climbing capacity | 6° |
| Motor | AC Induction Motor |
| Chassis Material | Steel Chassis ladder-type with overall metal roll cage |
| Suspension | Front and Rear: Leaf spring with shock absorbers |
| Breaking System |
Power front disc & rear drum brake system
Parking brake
|
| Steering and Transmission |
Power steering
Direct-drive function with forward-reverse selector
|
| Controller | AC Motor Controller |
| Battery Pack | Lithium-Ion battery pack |
| Charger | Lithium-Ion Battery charger, Input: 220Vac |
| Instrumentation | Digital |
| Safety System |
Emergency stop switch
Seatbelt (driver and front passenger)
Max speed Control
|
| Tires | 4 x 165/R13C tires + 1 spare on stock mags wheels |
| LIGHTING |
2 x Headlight with Hi/Lo Beam, turn signal, park light, with Daily Running Light (DRL)
2 x Side turn lamp
2 x Rear Round LED set (Brake/Running, Turn, Reverse)
2 x Dome light
2 x LED Fog Lamp
4 x Side clearance light
Rear plate light
|
| Accessories |
Upholstery seats
Rain cover
Back horn
Hand tools (3-ton hydraulic jack, EWD, tire wrench)
|
| Optional Upgrades |
12V power source for auxiliary devices
Seat side guard or doors
|
