CATEGORY |
SPECIFICATIONS |
|---|---|
| Body Material | Composite materials (non-metallic) |
| Color | Customer preference |
| Overall Dimension | 2.70M x 1.50M x 1.80M |
| Capacity | 6 passengers + 1 driver |
| Load Capacity | 450 kg |
| Range Per Full Charge | 60-80 km flat surface |
| Normal Operating Speed | 25 - 40 kph |
| Climbing capacity | 10° |
| Motor | 5.0 KW AC Induction Motor |
| Chassis Material | Steel Chassis |
| Suspension | Front: Fork double coil suspensions Rear: Leaf spring with shock absorbers |
| Breaking System |
Front & rear disc brake; Parking brake
|
| Transmission | Direct-drive function with forward-reverse selector |
| Controller | AC Motor Controller |
| Battery Pack | Lithium-Ion battery (ToJo Motors-battery only) |
| Charger | Lithium-Ion battery Charger, Input: 220Vac |
| Instrumentation | Digital |
| Safety System |
Emergency stop switch: Max speed control
|
| Tires | 4 x 12/450 tires |
| LIGHTING |
2 x Head light (H/L) with turn signal system
2 x Rear light with turn signal and reverse
1 x Dome light
|
| Others |
2 x side mirror (large)
1 x wiper
Upholstery seats (driver and passenger)
Laminated glass windshield
Rain Cover
PWD Ramps Access
|
