CATEGORY |
SPECIFICATIONS |
|---|---|
| Body Material | ABS/FRP |
| Color | Customer preference |
| Overall Dimension | 5.60 m x 1.75 m x 2.60 m |
| Capacity | 30 PAX (19 perimeter seating + 10 standing + 1 driver |
| Load Capacity | 2,100 kg |
| Default Range | 100 km on flat terrain, 80 Km on 50-100% load |
| Normal Operating Speed | 35 – 45 kph |
| Climbing capacity | 6° |
| Chassis Material | Steel Chassis ladder-type with overall metal frame cage |
| Drivetrain |
AC Induction Motor with motor controller
Single-speed and direct drive transmission
Rear wheel drive
|
| Suspension | Front and Rear: Leaf Spring with shock absorbers |
| Breaking System |
Power front disc & Power rear drum brake system
Parking brake
|
| Steering System |
Electronic Power Steering
|
| Battery and Charging |
Lithium-Ion battery pack
Main system-swapping type
|
| Instrumentation | Digital |
| Safety System |
Emergency stop button
Seatbelt (driver and front passenger)
Max speed Control
|
| Tires | 4 x 195/70 R15C tires + 1 spare on stock steel rim |
| LIGHTING |
2 x Headlight with Hi/Low Beam, turn signal, park light, with Daytime Running Light (DRL)
2 x LED Fog Lamp
2 x Rear Round LED light set (Brake/Running, Turn, Reverse)
Other lighting systems: dome light, side turn light, rear plate light clearance light.
|
| Accessories |
2-arm wiper (large)
Upholstery seats
Reversing back horn
Driver-controlled electric passenger door (single entry)
Hand tools (3-ton hydraulic jack, PWD, tire wrench)
|
| Aircon System |
20-pc perimeter air vents
Operating time 3~4 hours on single charge
|
| Additional Features |
CCTV with monitoring software
GPS and WiFi system-capable
LED scrolling text display
12V power source for auxiliary devices
|
