CATEGORY |
SPECIFICATIONS |
|---|---|
| Body Material | Abs Compisite Body Panels |
| Color | Customer preference |
| Overall Dimension | 2.70M x 1.50M x 1.80M |
| Capacity | 6 passengers + 1 driver |
| Load Capacity | 500 kg |
| Range Per Full Charge | 60-80 km flat surface |
| Normal Operating Speed | 25 - 40 kph |
| Climbing capacity | 10° |
| Motor | 5.0 KW AC Induction Motor |
| Chassis Material | Steel Chassis |
| Suspension |
Front: Fork double coil suspension
Rear: Leaf spring with shock absorbers
|
| Breaking System |
Front & rear disc brake; Parking brake
|
| Transmission | Direct-drive function with forward-reverse selector |
| Controller | AC Motor Controller |
| Battery Pack |
Lithium-Ion battery (ToJo Motors-battery only) (swappable)
Lithium-Ion battery charger, Input: 220Vac
|
| Instrumentation | Digital |
| Safety System |
Emergency stop switch
Max speed control
|
| Tires | 3 x 12/450 tires + 1 spare |
| LIGHTING |
2 x Head light and turn signal
2 x Rear light with turn signal and parking
1 x Dome light
|
| Others |
2 x side mirror (large)
Upholstery seats (driver and passenger)
Laminated glass windshield
Rain Cover
Top carrier (optional)
On-top lighted signage (optional)
|
